XDI 2500cc Injectors for 2017+ Civic Type R FK8 FL5

Looking to make BIG power with your Type R?

Upgraded turbos, built motors, and the parts that go along with them can quickly tax the OEM DI fuel system. When paired with the XDI High Pressure Fuel pump, these injectors deliver the increased flow needed to support these upgrades. Best of all, they are a direct bolt-in fitment application and compatible with common tuning systems such as Hondata and Motec.

The XDI Upgraded Fuel Injectors are designed to work seamlessly with the direct injection system found on your Honda. Simply remove the old injectors, replace them with the upgraded units, and flash the new tune to account for the additional flow. Please note that due to environmental concerns these injectors are for off-road use only and not to be used on public roads.

Specifications

Product Name: XDI FK8 CIVIC TYPE R 2500CC INJECTORS

Part Number: XDI-i016-110

Flow Rate: 2500cc/min

Kit Includes: 4x 2500cc Fuel Injectors

Maximum Rail Pressure: 200bar

Fuel Compatibility: all known fuels, all Ethanol blends

Electric Connector: Bosch Compact 2-pin

Driver Profile: XDI, integrated in Hondata FlashPro

Tuning Support: Standalone, MoTeC, Hondata, WinOLS

Injector Data

Flow Rates:

2500 cc/min at 100 bar

3500 cc/min at 200 bar

Increased Flow: +110% over OEM injectors

Performance: Rock-solid, perfectly linear

Fitment: 100% drop-in with optimized spray pattern

Cold Start & Idle: Perfect cold start and idle not expected

Requirements: HPFP60 recommended to fully utilize injector capacity

Fuel & Tuning: Pump gas not recommended; custom tuning required

Injector Testing and Documentation:

Each XDI injector set undergoes rigorous testing and matching at three critical operating points, with full documentation provided:

Idle Stability: 0.8 ms at 20 bar

Static Flow Reference: 10 ms at 100 bar

WOT Performance and Stability: 6 ms at 200 bar

Vehicle Compatibility

2017-2022 Honda Civic Type R (FK8)

2023-2024 Honda Civic Type R (FL5)

2024+ Acura Integra Type S (DE5)

Note: Tuning is required
